Description –

MSI H510M-B Motherboard

• Model: PRO H510M-B
• Chipset: INTEL H470
• CPU Support: Supports 10th Gen Intel Core, Pentium Gold, Celeron (LGA 1200)
• Memory:
  • 2x DDR4 slots, max capacity 64GB
  • Supports 2933/2666/2400/2133 MHz
  • Dual-channel mode, non-ECC, un-buffered memory
  • Supports Intel® Extreme Memory Profile (XMP)
• Onboard Graphics:
  • 1x HDMI™ (supports 4K at 30Hz)
  • 1x VGA (max resolution: 2048×1536 at 50Hz, 1920×1200 at 60Hz)
• Expansion Slots:
  • 1x PCI-E x16 slot (Gen PCIe 3.0)
  • 1x PCI-E x1 slot
• Storage:
  • 1x M.2 (supports PCIe 3.0 x4 / SATA mode, compatible with 2280/2260/2242 devices)
  • 4x SATA 6G ports
• USB Ports:
  • 4x USB 2.0 (Rear)
  • 4x USB 2.0 (Front)
  • 2x USB 3.2 Gen1 Type A (Rear)
  • 2x USB 3.2 Gen1 Type A (Front)
• LAN: Realtek® 8111H Gigabit LAN
• Audio: Realtek® ALC897 Codec, 7.1-Channel High Definition Audio
• Internal I/O Connectors:
  • 1x ATX Power Connector
  • 1x CPU Power Connector
  • 1x CPU Fan Connector
  • 2x System Fan Connectors
  • 2x Front Panel Connectors
  • 1x Chassis Intrusion Connector
  • 1x Front Audio Connector
  • 1x COM Port Connector
  • 1x RGB LED Connector
  • 1x TPM pin header (supports TPM 2.0)
  • 4x USB 2.0 ports
  • 2x USB 3.2 Gen1 Type A ports
• LED Feature: 4x EZ Debug LED
• Back Panel Ports:
  • HDMI™
  • VGA
  • USB 3.2 Gen 1 5Gbps (Type-A)
  • LAN port
  • Audio Connectors
  • USB 2.0
• Operating System Support: Windows® 10/11 64-bit
• PCB Dimension: mATX, 202mm x 236mm
• Warranty: 3 Years

MSI H510M-B Motherboard is one of the best Motherboard.
